Step 1

cert, key and DH files

We start by generating the certificates, key`s and the Diffie Hellman file.
We will do this with XCA.

With XCA we can set up a CA (Certificate Authority), generate and sign Server and client certificates / keys.
The certificates with associated private keys are stored in a database and then we export them for use on the server and client (s).

To save the files that we are going to create, we will create a folder named Database.

1. Create a
database.

Start XCA and click on File -> New DataBase.
Save the database with the name OpenVPN and enter a password.
We also need this password to be able to open the database again later if we still need it.

* Edit:
Templates added. First
download the XCA templates for this manual.
Then import it on the Templates tab in XCA before following the following steps.
*

What if we want to generate more certificates for the benefit of multiple clients?
For that we will have to repeat the steps to generate and export client certificates and client keys.
These are steps 4. 8. 9.
For each client, enter the exact username that he / she has in DSM, in the commonName and Internal name fields , commonName is a requirementInternal name is for recognisability.
Each of the clients must also be a user in DSM and must have the rights to use VPN, you set this in the VPN Server under Rights.

2.
Generate CA.

Click on the Certificates -> New Certificate tab.
On the Source tab we select:
Create a self signed certificate with the serial 1
Signature algorithm SHA 256
CA
Click Apply all.

On the Subject tab, we enter CA for Internal name and commonName.
Click Generate a new key.
The following screen: CA, RSA, 4096 bit and click Create.

On the Extensions tab we set the Time range to 10 Years and click Apply.

On the Key usage tab we select on the left:
Digital Signature
Key Encipherment
Data Encipherment
Key Agreement
Certificate Sign
CRL Sign
On the right we do not select anything.

On the Netscape tab, we only remove the comment and click on Ok.

Now we have generated a CA with which we can sign the server and client (s) certificates.
This CA now appears under the Certificates tab.

3.
Generate server certificate.

On the Certificates -> New certificate tab.
On the Source tab we select:
Use this Certificate for signing CA
Signature algorithm SHA 256
SERVERCERT
Click Apply all.

On the Subject tab, we fill in Internal name and commonName Server.
Click Generate a new key.
The following screen: Server, RSA, 4096 bit and click Create.

On the Extensions tab we set the Time range to 5 Years and click Apply.

On the Key usage tab we select on the left:
Digital Signature
Key Encipherment
On the right we only select TLS Web Server Authentication.

On the Netscape tab, we de-select everything and remove the comment and click OK.

Now we have generated a Server certificate that will be placed on the OpenVPN Server.
On the certificates tab, click on the arrow next to the CA so that it appears.

4.
Generate client certificate. (Repeat for multiple clients)

On the Certificates tab -> New certificate.
On the Source tab we select:
Use this Certificate for signing CA
Signature algorithm SHA 256
CLIENTCERT
Click Apply all.

On the Subject tab, we enter the Internal name and the CommonName client. (For multiple clients, enter the username)
Click Generate a new key.
The following screen: username, RSA, 4096 bit and click Create.

On the Extensions tab we set the Time range to 5 Years and click Apply.

On the Key usage tab we select on the left:
Digital Signature
Key Agreement
On the right we only select TLS Web Client Authentication.

On the Netscape tab, we deselect everything and remove the comment and click OK.

Now we have generated a client certificate that will be placed on the OpenVPN client.

5.
Export CA.

On the Certificates tab, select CA and click Export.
Choose the Database folder that we created earlier.
Export Format PEM and click Ok.

6.
Export server certificate.

On the Certificates tab, select Server and click Export.
Choose the Database folder that we created earlier.
Export Format PEM and click Ok.

7.
Export server private key.

On the Private Keys tab, select Server and click Export.
Choose the Database folder that we created earlier.
Export Format PEM and click Ok.

8.
Export client certificate. (Repeat for each client)

On the Certificates tab, select client and click Export.
Choose the Database folder that we created earlier.
Export Format PEM and click Ok.

9.
Export client private key. (Repeat for each client)

On the Private Keys tab select client and click Export.
Choose the Database folder that we created earlier.
Export Format PEM and click Ok.

10.
Generate Diffie Hellman parameters.

Click on Tools -> Generate DH parameter (XCA version older than 1.3.2 under File)
DH parameter bits 4096 and click on Ok.
This will take a while, let it go, have a drink and wait …..
Have a drink …..
…..
….
…
..
Choose the Database folder that we created earlier and click Ok.

If it went well, we now have in the database directory the following files:

Openvpn.xdb
ca.crt
client.crt (or <username> .crt)
client.pem (or <username> .pem)
dh4096.pem
server.crt
Server.pem
Rename client.pem to client.key (or <username> .key)
Rename Server.pem to Server.key

Step 2

Install and set up the VPN Server.

In the Package Center we find the VPN Server under Utilities.
After it has been installed and started, we will do some settings.

Open Main Menu and click on VPN Server.
In the screen we now see the overview.

Under Rights we now first distribute the rights.

Under PPTP and L2TP we do not give anyone any rights unless you use it too.
Click Apply.

Go to OpenVPN, left in the menu.

In this screen we check:
Enable OpenVPN server Enable
compression on the VPN link
Clients give access to the LAN server

Dynamic IP address: 192.168.160.1
Click Apply.

The rest can stay that way.

Now stop the VPN Server in the Package Center.

Avoid IP / route conflicts.
We are dealing with three subnets:
1. The network where the VPN Server / DS is located (local network)
2. The Dynamic IP address of the VPN (tunnel network)
3. The remote network from which you connect to a VPN client (Telephone, Laptop, Tablet, etc.)
These must be separate subnets.

Because you hardly ever have any influence on the IP address that your client gets from the remote network, it is therefore wise to choose the network where the VPN Server / DS is located as well as Dynamic IP address somewhere in the middle.
For the local network eg: 192.168.150.xxx (instead of the standard subnets that router manufacturers use, see list below )
For the Dynamic IP address, for example: 192.168.160.1
The chance that the remote network from which you connect with the client to the VPN Server / DS, uses the same subnet, becomes smaller.

Useful private subnets are:
Class A: 10.0.0.0 – 10.255.255.255 (10.0.0.0/8)
Class B: 172.16.0.0 – 172.31.255.255 (172.16.0.0/12)
Class C: 192.168.0.0 – 192.168.255.255 ( 192.168.0.0/16)

The list below are standard subnets that manufacturers use, ie as far as I have been able to find.
You do not want to use it as a local network or Dynamic IP address.


10.0.0
10.0.1
10.1.1
10.1.10
10.2.0
10.8.0
10.10.1
10.90.90
10.100.1
10.255.255

169.254 # APIPA #

172.16.0
172.16.16
172.16.42
172.16.68

172.19.3

172.20.10 # IPhone built-in hotspot #

192.168.0
192.168.1
192.168.2
192.168.3
192.168.4
192.168.5
192.168.6
192.168.7
192.168.8
192.168.9
192.168.10
192.168.11
192.168.13
192.168.15
192.168.16
192.168.18
192.168.20
192.168.29
192.168.30
192.168.31
192.168.33
192.168.39
192.168.40
192.168.42 # Android USB tethering #
192.168.43 # Android built-in hotspot #
192.168.50
192.168.55
192.168.61
192.168.62
192.168.65
192.168.77
192.168.80
192.168.85
192.168.88
192.168.98
192.168.99
192.168.100
192.168.101
192.168.102
192.168.111
192.168.123
192.168.126
192.168.129
192.168.137 # Windows Phone built-in hotspot #
192.168.168
192.168.178
192.168.190
192.168.199
192.168.200
192.168.220
192.168.223
192.168.229
192.168.240
192.168.245
192.168.251
192.168.252
192.168.254

200.200.200

In the router, UDP port 1194 must be forwarded to the NAS.
Register on the forum for the router and possibly the firewall because this is specific to everyone.

If you do not yet use “Automatic blocking”, it is now time for that.
Control panel -> Security -> Automatic blocking

Each DS model has a maximum number of VPN users that you will find in the specifications of your model.

Now we leave the VPN Server and go “under the hood”.

Step 3

Adjust the VPN Server.

Now we are going to put the certificates and keys that we created in Step 1 in the right place.
We are also going to make a ta.key that is needed on the server and client for extra protection.

First a summary of what that reads:

/ usr / synonym / etc / packages / VPNCenter / VPNcerts
ca.crt
server.crt
server.key
dh4096.pem
ta.key

/ usr / synonym / etc / packages / VPNCenter / openvpn
Here you will find openvpn.conf.user.

1. WinSCP

Navigate to: / usr / syno / etc / packages / VPNCenter
Create a new folder named:
VPNcerts

Copy the newly created CA.crt, Server.crt, Server.key and dh4096.pem to the folder.
Permissions as follows:
0400 for CA.crt, Server.crt, Server.key
0400 for dh4096.pem We set

permissions in WinSCP with right-mouse-button-> properties on the relevant file.

2. PuTTY (Terminal is also present in WinSCP. See menu Commands -> Open Terminal)

SSH to the NAS and type the following one after the other:

cd /usr/syno/etc/packages/VPNCenter/VPNcerts
Depending on the DS model, there may not be an Apparmor present.
To generate the ta.key we must first stop Apparmor:

/usr/syno/etc.defaults/rc.sysv/apparmor.sh stop
generate ta.key:

openvpn --genkey --secret ta.keyThere is now a ta.key in the VPNcerts folder.
Permissions (with WinSCP) as follows:
0400 for ta.key
The ta.key will also be needed in the OpenVPN Connect App.
Handy if you now copy it to the Database folder with WinSCP.

Restart Apparmor:

/usr/syno/etc.defaults/rc.sysv/apparmor.sh start
And finally:

exit
3. WinSP

Navigate to / usr / syno / etc / packages / VPNCenter / openvpn

Download the openvpn-server.zip configuration file at the bottom of this post, unpack it and follow the instructions in openvpn.conf.user. You can open / edit the file with a double click in WinSCP.
Place openvpn.conf.user in the above folder with rights 0400.

If everything is done correctly, we are ready on the VPN Server and you can now start it via the Package Center.

If you get a message in VPN Server to check the configuration file, stop the VPN Server.
Use WinSCP to navigate to / var / log and open openvpn.log to see what the message is.

Step 4

Put your SD card from the phone in the PC and create a folder with the name VPNcerts.
Copy the files that we created in the first step to this folder.
CA.crt, client.crt and client.key. (or CA.crt, username.crt and username.key) Also

copy the ta.key from step 3 here.

Download the openvpn-client.zip configuration file at the bottom of this post, extract it and follow the instructions in openvpn.ovpn You can open / edit the file with a double click in WinSCP.
Place openvpn.ovpn also in the VPNcerts folder and then you put the sd card back in the phone.

Download OpenVPN Connect from OpenVPN in the Play store and install it.
Open the App and import Profile from SD card.
Navigate to the VPNcerts folder on the sd card where we have stored the CA, crt, key, ta and ovpn.
Select the openvpn.ovpn profile and enter your username and password.

The rest of the files are automatically imported with the openvpn.ovpn profile.
This means that if you edit the profile, you will have to import it again.
Once the connection works you can delete the VPNcerts folder for security reasons.

There is also an option to save CA.crt, client.crt, client.key and ta.key in the ovpn profile.
Then you only have to hand over one file to a user.
This option, called “Inline file support” can be found here .
